一、Instrument Overview：
The KODIN 9 series PL pipeline detector can apply a special frequency signal current to the tested pipeline.
The operator can measure the magnitude and direction of the signal current applied by the system transmitter, and the receiver performs necessary calculations to obtain the calculation results through measurement. It is possible to accurately locate pipelines without excavating the soil cover.
The KODIN 9 series PL pipeline detector is equipped with an Android system and can obtain measurement parameters in the system's built-in app. When connected to WIFI, real-time drawing, surveying, and detection results can also be directly shared on mobile phones or computers.
二、Technical Specifications：
Matching transmitter model: S10
Transmitter frequencies: 128Hz, 512Hz, 640Hz, 1kHz, 2kHz, 4kHz, 8kHz, 33kHz, 65kHz, 83kHz
Receiver receiving frequency: 128 Hz、512Hz、640Hz、1kHz、2kHz、4kHz、8kHz、33kHz、65kHz、83kHz、POWER、CPS、RADIO、CATV、PASIV
Depth measurement accuracy: ± 5%
Current measurement accuracy: ± 5%
Leakage point positioning accuracy: ± 10cm
GNSS satellite positioning accuracy: RTK centimeter level
Positioning coordinate format conversion: support
Real time point distance: supported
Data Storage: Supports
Export data: Excel, Word, ZIP
Integrated detection and surveying: support
A-frame: optional
Customized APP: Supports
Pipeline positioning accuracy: ± 5% of depth (0-3m)
Transmitter connection output methods: direct connection, clamp, induction
Output current of transmitter: up to 500mA
Transmitter lithium battery power supply: built-in 12.6V 13000mAh lithium battery
Transmitter power: 10W
Receiver display screen: 4-inch IPS touch LCD screen
Receiver data interface: wireless communication and USB interface
Storage method: 16GB eMMC, expandable 32GB TF card
Usage environment: Relative humidity: ≤ 90%; Temperature: -10 ℃ to+40 ℃
Receiver battery: 3.7V 12000mAh lithium battery
Receiver operating time: 10-20 hours
三、Site of use：
四、Standard product packing list：
1、KODIN 9B-PLx接收機(jī) 1
1. KODIN 9B PLx Receiver 1
2. KODIN 9B PLx transmitter 1
3. KODIN 9 Series PL Receiver Handbag 1
4. 12.6V 3A power adapter 1
5. 4.2V 2A power adapter 1
6. Micro USB data cable 1
7. Output Line 1
8. Iron file 1
9. Grounding nail 2
10. Magnetic attraction 1
11. SIM card removal needle 1
Optional accessories：
1. KODIN 9B PLx receiver battery compartment (with battery)
2. A-frame (with A-frame connecting wire)
3. 52mm (2-inch) clamp
4. 122mm (4.8-inch) clamp
5. Screen protector
-
